    Output Voltage DC 24V Industrial Power Supplies

    Ask Lasest Price
    Brand Name : ESTEL
    Model Number : GPAD531M27-3A
    Certification : ISO9001, CE, 3C, FCC, TLC
    Price : negotiation
    Payment Terms : L/C, T/T, D/A, D/P, Western Union
    Supply Ability : 50,000 sets per month
    Delivery Time : 7-10 working days
    • Product Details
    • Company Profile

    Output Voltage DC 24V Industrial Power Supplies


    Industrial Power Supplies For Industrial Device, Input Voltage: 165~300Vac, Output Voltage: 24Vdc, Output Power: 530W


    Quick Details:


    Place of Origin: Shenzhen, China (Mainland)Input Voltage: AC220V
    Brand Name: ESTELOutput Voltage: DC24V
    Model Number: GPAD531M27-3AOutput Power: 530W
    Product Name: Industrial Power SuppliesInput Frequency: 47~63Hz
    Certification: ISO9001, CE, 3C, FCC, TLCMax. Output Current:16A
    Application: Industrial Equipment

    Payment & Shipping Terms:


    Minimum Order Quantity:1 set
    Price:negotiation
    Payment Terms:L/C, T/T, D/A, D/P, Western Union
    Supply Ability:50,000 sets per month
    Delivery Time:7-10 working days
    Packaging Details:carton/wooden case

    1. Description


    The GPAD531M27-3A industrial power supply is with wide input voltage range (165 to 300Vac), with multiple way output. The power system is equipped with protections against output short-circuit, over-current and output over-voltage. The power supply is designed strictly in accordance with the safety regulations, which conforms to the safety standards and requirements of information technology.


    2. Specifications

    Technical Parameters


    Environment
    ParameterMin.TypicalMax.UnitRemark
    Operating Temperature-402570°C
    Storage Temperature-452585°C
    Relative Humidity1095%non-condensing
    Altitude03000m
    Atmospheric Pressure70106KPa
    CoolingNatural conduction heat dissipation

    Input
    ParameterMin.TypicalMax.UnitRemark
    Input Voltage Range165220300Vac
    Input nominal voltage220Vac
    Input Frequency4763Hz
    Power Factor

    Output
    ParameterMin.TypicalMax.UnitRemark
    Output Voltage Range+28V242830VdcAdjustable
    +9V9912Adjustable
    Output Current Range+28V016A
    +9V08
    Load Regulation±1.5%
    Stabilized Voltage Precision±1.5%
    Line Regulation±0.5%
    Ripple (Vp-p)+28V150mV

    Rated input/output,

    apply a 0.1uF ceramic capacitor and 10uF electrolyte capacitor,

    oscilloscope bandwidth of 20MHz.

    +9V100

    Other Output
    ParameterMin.TypicalMax.UnitRemark
    Output Power477530W
    Output efficiency8688%Rated input, full load output
    Temperature Coefficient±0.02%/℃
    Start-up Output Delay6SRated input and output, the input to each output to rise to 90% of the time.
    Start-up/shut-down overshoot range±5%
    Output Voltage Rise Time5500msStart-up under rated input and output conditions, the output voltage rise from 10% to 90% of the time, and requires monotonic rise in the output waveform.
    Capacitive load2200uF

    Protection
    ParameterMin.TypicalMax.UnitRemark
    Input Over Voltage Protection305320VacHalf load test
    Input Over Voltage Protection Recovery290310Vac
    Input Under Voltage Protection140160VacHalf load test
    Input Under Voltage Protection Recovery150165Vac
    +28V Output Over Voltage Protection Point30.534VCan be automatically recoverable
    +28V Output current limiting Protection Point17.624AOther road with a full load test, can be automatically recoverable
    +9V Output current limiting Protection8.513.5ACan be automatically recoverable
    Short Circuit ProtectionCan be long-term short circuit and can be automatically recoverable
    Over temperature Protection℃Over temperature Protection function

    EMC And Other
    ParameterStandard Requirements
    Radiation emission (CE)EN55022 - Class B
    Conduction interference (RE)EN55022 - Class B
    SurgeEN61000-4-5 LEVEL level 3, line - line 2KV, line - ground 4 KV
    Electrostatic discharge (ESD)EN61000-4-2 contact discharge:±6KV, air discharge: ±8KV.(Criterion B)
    Radiated immunity (RS)EN61000-4-3 test frequency: 80MHz～1000MHz, 1.4GHz～2GHz; electric field intensity: 3V/m; amplitude modulation:80%AM(1kHz)
    Conducted immunity (CS)EN61000-4-6 test frequency: 0.15 MHz～80 MHz, test intensity: 3V, amplitude modulation: 80%AM(1kHz)
    Electrical Fast Transient(EFT)EN61000-4-4 ±2KV
    Voltage dips and short interruptionsEN61000-4-11 dropped to 70% Ut, duration time is 500mS; fall to 0% Ut, duration time is 20ms; fall to 0% Ut, duration time is 10ms (half cycle); drop to 0% Ut, duration time is 5000ms; criterion B, criterion C
    Lightning current

    Line-line ± 5kA

    Line-earth ± 5KA

    (8 / 20us) surge current plus and minus separately 5 times, each time has one minute interval (line - line, line - to be tested), there is no damage for device, the power supply can work properly after the test.

    VibrationFrequency 1-4Hz, acceleration spectral density 0.0001g2 / Hz; frequency 4-100Hz, acceleration spectral density 0.01g2 / Hz; frequency 100-200Hz, acceleration spectral density 0.001g2 / Hz; total root mean square acceleration: 0.781Grms; test axial: 3 axially. test time: each axial 30min.
    ImpactImpact waveform: half sine wave; peak acceleration: 300m/s2; pulse width: 6ms; impact axis: 6 direction; impact times: 3 times in each direction.
    Collision testCollision waveform: half sine wave; peak acceleration: 180m/s2; pulse width: 6ms; collision direction: 6 direction; collision frequency: 100 times in each direction.
    Drop test

    Surface, corner , edge drop:

    The weight range ≤15kg, the drop height 100cm, the drop of a corner, 3 edges and 6 face:

    1 corner: If you can determine which one is the weakest corner, this bottom corner will drop as the object; if you can not judge, choose angular 2-3-5.

    3 edges: three edges intersect at this bottom corner.

    6 surfaces: six outer surface of the package ;

    Fall times: 1 time per face

    Hydrostatic pressure test

    TL=Wt×(S-1)×F×9.8(N)

    Wherein: TL: applied pressure values, the unit is N; Wt: the weight of the package itself, the unit is kg; S: Allowable stacking layers numeber , select the maximum stacking layers number; F: safety coefficient, is usually 5; holding time for applying pressure is 2h.

    Moisture proofGB/T2423.4-1993 alternating damp heat test, 24～45℃, 95％RH, 48h
    Anti-fungalGB/T2423.16-1999 fungus test, level 2
    Heat dissipation methodModule naturally conduct and dissipate heat
    Noise55dB(A); test distance is 1m
    MTBFMTBF≥200,000h
    Annual return rate≤1%
    SmellingAny abnormal and poisonous smelling is not allowed

    Insulation Rating
    ParameterStandard RequirementsNote

    input Output


    		1500Vac/10mA//1minNo arc, no breakdown, put off discharge tube when testing

    Input - Earth


    		1500Vac/10mA//1min

    Output - earth


    		500Vdc/10mA//1min

    Leakage current


    		≤3.5 mA264Vac
    Ground Resistance＜0.1Ω
    Insulating Resistance≥10MΩIn normal atmospheric pressure, when relative humidity is 90%, testing voltage is 500VDC, the insulating resistance of input-output, input-grounding, output-grounding are all ≥10MΩ

    Mechanical Specifications
    L*W*D260*88*48.5mm
    Weight (kg)≤Kg

    The goods can be shipped by sea, by air, by courier, by land, by train, etc.


    3. Alarm



    Alarm signal
    AC/OK Alarm

    AC input abnormal: output logic low electrical level (0V～+0.5V);

    AC input normal: output logic high electrical level (+4.7V~+5.3V);

    DC/OK Alarm

    Output abnormal: output logic low electrical level (0V～+0.5V);

    Output normal: output logic high electrical level (+4.7V~+5.3V);

    Working IndicatorWhen power input is normal, the green light is on; when power input is abnormal, the green light is off. Φ5 green light
    When power output is normal, the green light is on; when power output is abnormal, the green light is off. Φ5 green light
    Output Switch ControllerOutput switch controller controls internal power supply protection circuit signal electric potential by rocker switch on the panel to achieve output power off and on.

    4 Packing and Shipping



    Our Delivery Agent


    Besides the following delivery agent, we can also look for the delivery agent with the best price in china if you need us to do for you.



    5. Our Contact Information


    Mobile Phone: 0086-13752765943

    Telephone: 0086-0755 66600941

    Email: info@estel.com.cn

    lxf.estel@hotmail.com
    Skype: fiona.liang10


    6. Our Partner
