    Outdoor Cabinet Air Conditioner / Panel Board Air Conditioner For Outside Plant Access Cabinet

    Ask Lasest Price
    Brand Name : ESTEL
    Model Number : TC06-200JFH/01(KT029)
    Certification : ISO9001, CE, 3C, FCC, TLC
    Price : negotiation
    Payment Terms : L/C, D/A, D/P, T/T, etc
    Supply Ability : 10,800 sets per month
    Delivery Time : 7-10 working days
    • Product Details
    • Company Profile

    Outdoor Cabinet Air Conditioner / Panel Board Air Conditioner For Outside Plant Access Cabinet


    Outdoor Cabinet Air Conditioner / Panel Board Air Conditioner For Outside Plant Access Cabinet


    Quick Details:


    Place of Origin: Shenzhen, China (Mainland)Rated Cooling Capacity : 2000W
    Brand Name: ESTELRated Heating Capacity:300/500W (optional)
    Model: TC06-200JFH/01(KT029)Dimension: H×W×D 750×500×230mm
    Product Name: Outdoor Cabinet Air ConditionerInput Voltage: AC220V/50Hz
    Certification: ISO9001, CE, 3C, FCC, TLCRated Input Current: 2.8A
    Cover: including outer coverRated Input Power: 616W
    Color: greyWorking Temperature: -20°C ~ +55°C
    Protection Level: IP55Noise: ≤65dB
    Installation Mode: door mounted, side mountedRefrigerant: R410A
    Support OEMCooling Method: compressor, active cooling

    Payment & Shipping Terms:


    Minimum Order Quantity:1 set
    Price:negotiation
    Payment Terms:T/T, L/C,DA,DP, etc
    Supply Ability:10,800 sets per month
    Delivery Time:7-10 working days
    Packaging Details:carton + wooden case

    1. Specifications

    (1) Technical Parameters


    Environmental Performanceworking environmental temperature-20°C ~ 55°C
    storage temperature-40°C ~ 70°C
    working humidity≤95%
    Thermal Performancerated cooling capacity

    2200W(L35 L35)

    2000W(L25 L35)

    rated heating capacity300/500W (optional)

    Electrical Performance

    rated input current

    3.0A(L35 L35)

    2.8A(L25 L35)

    rated input power

    660W(L35 L35)

    616W(L25 L35)

    rated input voltageAC220V~240V/50Hz
    RefrigerantR410A
    Noise≤65dB

    Dimension Diagram: H×W×D: 750×500×230mm



    ModelABCDEFGHIJK

    TC06-200JFH/01

    (KT029)

    220474460600724750198230700450500

    Door Hole-opening Diagram(mm):


    Size

    Model

    SpecsLMNOPQR

    TC06-200JFH/01

    (KT029)

    2000W474460220724708600460

    Installation Diagram:



    2. Description


    Cabinet air conditioner is actively cooling with compressor, and it will remove the heat inside the cabinet to outside. It can also keep the dust and heat outside the cabinet, avoiding problems from using fans. The cabinet inside can be maintained at an ideal temperature for electrical components which effectively guarantees the stability of the electronic equipment and improves the reliability of the whole system.


    3. Application


    The air conditioner is widely used for outdoor telecommunication cabinet, battery cabinet, electric cabinet, industry control cabinet, power cabinet, rectifier cabinet, UPS cabinet, BTS cabinet etc.

    4. Features


    • Strong adaptability
    • High intelligence
    • High precision
    • High reliability
    • Low noise
    • Low energy consumption
    • With 4 way switching value detection
    • With 1 way room air conditioner control
    • Voltage input range: 220VAC±15% 50Hz
    • With dry contact alarm output

    5. System Principle Diagram


    6. Electrical Wiring Diagram



    Wiring Ports:


    L N PE : power supply port (voltage input: 220VAC±15% 50Hz)

    F+ F- : direct ventilation output port

    AL1 AL2: general alarm output port

    A+ B- SGND: RS485 communication port

    N: not connected pin

    7. System Control

    7.1 Function and Application


    ET731 intelligent air conditioner controller is a universal intelligent controller, controlling with highly integrated STC SCM. It can intelligently control thermostatic cabinet air conditioner working and hydrogen exhausting, including functions such as fault self diagnosis, power-on self start, or restart after unexpected failure caused by other reasons. The controller is compatible with all types of air conditioners in the market.


    The controller, with the features of advanced performance, easy installation and setting, are widely used in telecom cabinet, small and medium sized telecom room, UPS room, outdoor base station room, etc.

    7.2 Technical Parameter


    • 2×16 Chinese/English shift LCD display, user friendly;
    • Simultaneously display temperature and humidity inside the box and communication room temperature;
    • Temperature measurement accuracy: 0.1 °C; humidity measurement accuracy:5%;
    • Can store 180 days’ daily event record, 1 record every day;
    • Daily highest temperature, lowest temperature, average temperature
    • Daily event record;
    • Save the former day’s daily data at 0:00 every day; Can query 180 days’ daily record information;
    • RS485 communication, YD/T 1363.1-2005 standard protocol, support remote detection and control;
    • Control mode: pulse (Non dry contact air conditioner), conducting (dry contact air conditioner)
    • Real-time control air conditioner on/off
    • Power supply: AC185V~264V/50Hz;
    • Power consumption:≤5W;
    • Working environment: -30°C~70°C; <90%RH;
    • Installation method: guide rail, hanging;
    • Dimension(L×W×H):150mm×190mm×45mm

    7.3 Operating Instruction


    ET731 uses English interfaces, which can be operated easily. All the operations can be realized with four buttons. The following is the control board diagram:



    a. Check operating parameters of key parts inside air conditioner, namely observation parameter. Operation steps:



    Observation Parameter: on the left of line 1 is Parameter No. (PAnn); on the right of line 1 is parameter value. Line 2 shows the remark of the parameter.


    b. Revise operating parameters of air conditioner, namely control parameters. Operation steps:



    Control Parameter: on the left of line 1 is Parameter No. (PCnn), on the right of line 1 is parameter value. Line 2 shows the remark of the parameter.


    c. Revise basic parameters of air conditioner. Operation steps:



    Basic Parameter: on the left of line 1 is Parameter No. (PBnn), on the right of line 1 is parameter value. Line 2 shows the remark of the parameter.


    d. Manual Operation Mode:


    Operation steps:



    Enter the interface to select “Cool” (cooing), “Heater” (heating), “Air” (direct ventilation) to conduct manual start (ON) and stop (OFF) operation.


    e. Event Query Mode:


    Operation steps:


    8. Mainboard Wiring Diagram



    9. Packing and Shipping




    Our Delivery Agent


    The goods can be shipped by sea, by air, by courier, by land, by train, etc.

    Besides the following delivery agent, we can also look for the delivery agent with the best price in china if you need us to do for you.
