Quick Details:
| Place of Origin: Shenzhen, China (Mainland) | Rated Heat Exchange Capacity: 120W/K |
| Brand Name: ESTEL | Rated Heating Capacity:300/500W (optional) |
| Model: HE06-120SEH/T | Input Voltage: DC48V |
| Product Name: Heat Exchanger for Outdoor Cabinet | Rated Input Current: 2.95A |
| Certification: ISO9001, CE, 3C, FCC, TLC | Rated Input Power: 142W |
| Cover Material: galvanized steel | Working Temperature: -20°C ~ +55°C |
| Protection Level: IP55 | Noise: 59dB |
| Installation Mode: top mounted | Dimension W×D×H: 482.6×500×310mm |
| Support OEM | Cooling Method: heat pipe heat exchanger |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Payment Terms: | T/T, L/C, etc |
| Supply Ability: | 16,000 sets per month |
| Delivery Time: | 10-15 working days |
| Packaging Details: | carton + foam + wooden case |
1. Technical Parameters
| Model | HE06-120SEH/T |
| Performance Parameters |
| Rated Voltage (V) | DC48V |
| Rated Current (A) | 2.95 |
| Heat Exchange Capacity (W) | 1200 |
| Heater Power (W) | 300 |
| Rated Power (W) | 142 |
| Circulation Air Volume (m3/h) | 820 |
| Noise (dB(A)) | 59 |
| Refrigerant | Mixed Liquid |
| Working Temperature | -20°C ~ 55°C |
| Mechanical Parameters |
| Installation Mode | Top Installed |
| Height (mm) | 310 |
| Width (mm) | 482.6 |
| Depth (mm) | 500 |
| Controller Parameters |
| Working Voltage (V) | DC36~72 |
| Working Temperature and Humidity | -20°C ~ +80°C, <90%RH |
| Temperature Control Accuracy (°C) | 0.1 |
| Power Consumption (W) | 5 |
| Communication Mode | Dry contact,RS485, RS232, GPRS |
2. Description
Because of the structural problem of heat exchange core, the
power-heat ratio of traditional plate heat exchanger is limited to
4~6, and the attenuation value of heat exchange will become higher
and higher after a period of operation. After applying the new type
double siphon heat pipe heat exchanger, which lowers the coolant
flow resistance through two groups of siphon heat pipes, the
power-heat ratio is 10 and higher, Meanwhile, in virtue of the
parallel-flow heat exchange technology, the air resistance is 2/3
lower than the traditional plate. Accordingly, it can not only save
almost half energy consumption and extend the internal of
maintenance twice and more during the long-term operation.
3. Application
The product is widely applied in telecom cabinet, small and medium
sized telecom room, UPS room, outdoor base station room, outdoor
advertising machine, bank ATM banknote exchange room etc.
4. Features
(1) Reliable: 48V DC power supply, works well even when AC power
fails
(2) Low noise
(3) Corrosion protection: Power coated sheet metal endures harsh
environment
(4) Easy maintenance: IP55 designed for flushing
(5) Compliant with the RoHS requirements
(6) Monitoring: Provide comprehensive alarm and status report
through RS485 interface for remote control
5. Electrical Wiring Diagram
Wiring Ports:
0V -48V: power supply input (voltage input: DC36 - 65V)
A+ B- SGND: RS485 communication interface
AL1 AL2: general alarm output
F+ F- : auxiliary direct ventilation control output (output voltage:
DC48V)
6. System Control Wiring Diagram
7. Packing and Shipping
Our Delivery Agent
The goods can be shipped by sea, by air, by courier, by land, by
train, etc.
Besides the following delivery agent, we can also look for the
delivery agent with the best price in china if you need us to do
for you.
