16U Double Wall and Floor Mounted Cabinet, 19 Inch Rack Cabinet Anti-Rust Anti-Water Anti-thief
Model: G1611154007
1. Cabinet Features
The cabinet is dustproof, rainproof and sunproof, that is used in
the outdoor place.
The cabinet has fans for cooling. The layout of the cabinet is
reasonable, which will facilitate cable access, fixing and
grounding. There’re individual entry holes for the power cables,
signal cables and optical cables.
All the cables used in the cabinet are made from flame retardant
materials.
2. Technical Specifications
2.1 Applicable environment conditions:
Environment temperature: -40°C ~ + 60°C
Environment humidity (RH): ≤95% (at + 40°C)
Air pressure: 70kPa ~ 106kPa
2.2 Material: hot dip galvanized steel
2.3 Surface treatment: derusting, degreasing,rustproof phosphating
(or galvanizing), powder coated.
2.4 Cabinet load bearing: ≥300kg
2.5 Ingress protection: IP55
2.6 Flame retardance: comply with GB5169.7 test A
2.7 Insulation resistance: the insulation resistance between
grounding devices and cabinet body parts is not lower than
2X104M/500V(DC).
2.8 Withstand voltage: the withstand voltage between grounding
devices and cabinet body parts is not lower than 3000V(DC)/1min.
2.9 Mechanical strength: each surface can bear upright
pressure＞980N; after the door is open, its outer end can bear
upright pressure ＞200N.
3. Quick Details
| Place of Origin: Shenzhen, China (Mainland) | External Size: W×D×H 500mm×500mm×900mm |
| Brand Name: ESTEL | Structure: double wall, with insulation, sandwich structure. |
| Model: G1611154007 | Protection Level: IP55 |
| Product Name: Outdoor Wall and Floor Mounted Cabinet | Cabinet Layout: one compartment, for installing 19” equipment |
| Certification: ISO9001, CE, 3C, FCC, TLC, IP55 | Cabinet Lock: anti-theft three point lock |
| Application: outdoor telecom base station | Cable Entry: at cabinet bottom |
| Material: galvanized Steel | Illumination: DC48V LED lamp |
| Heat Insulation: PEF | Cabinet Door: one front door |
| Color: white, grey (support custom made) | Cooling: fans |
| Coating: anti-corrosion outdoor powder coating | Installation: wall mounted(also support floor mounted) |
Payment & Shipping Terms
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 9,000 sets per month |
| Delivery Time: | 10-15 working days |
| Packaging Details: | wooden case |
4. Application
This outdoor telecom cabinet is wall mounted support floor mounted.
It widely is used in wireless communication base station, such as
3G system, communication/network integrated service,
access/transmission switching station, emergency
communication/transmission, etc.
5. Specifications
(1) Technical Parameters
| Item | Type | Technical Parameter |
| Structure | Dimension | External Size: W×D×H 500mm×500mm×900mm |
| Layout | One compartment |
| Equipment Installation Method | 19” standard rack |
| Door | With one front door, and anti-theft three point lock for outdoor
cabinet (support padlock) |
| Material | 1.Galvanized steel; 2.Double wall, thickness of outer plate: 1.5mm, thickness of inner
plate: 0.8mm, with heat insulation between two walls. |
| Structure | Assembled |
| Ingress Protection | IP55 |
| Temperature Control | Cooling | DC48V fans |
| Lighting | LED lamp | 48V LED lamp |
| Temperature | Temperature | Working Temperature: -20°C ~ 55°C |
| Storage Temperature: -40°C ~ + 70°C |
| Transport Temperature: -50°C ~ +70°C |
| Humidity | Relative Humidity | 5% ~ 100% |
| Pressure | Air Pressure | 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude) |
| Radiation Intensity | Solar Radiation Intensity | 1124 × (1±5%)W/m2 |
Accessories List
| No. | Item | Quantity | Unit | Specs |
| 1 | Outdoor Telecom Cabinet | 1 | Set | (1)External Size: W×D×H 500mm×500mm×900mm Internal Size: W×D×H 16U× 400×19” (2) One compartment; (3) With one front door, and anti-theft three point lock for
outdoor cabinet (support padlock). (4) Material: galvanized steel; double walls, thickness of outer
plate: 1.5mm, thickness of inner plate: 0.8mm, with 20mm PEF heat
insulation between two walls. |
| 2 | Fans | 4 | PC | DC48V |
| 3 | Door Sensor | 1 | PC | Used for controlling led lamp |
| 4 | LED lamp | 1 | PC | DC48V |
| 5 | Package | 1 | Set | Wooden Case |
6. Structure and the attachment
The cabinet is made of hot dip galvanized steel, double walls
structure. There are heat insulation between the two walls. It is
easyly installed with perfect sealing performance.
Equipment Compartment: The cabinet is used for installing telecommunication equipments.
The cabinet is a double-wall cabinet, with 20mm heat insulation
between the two walls. It uses 4 fans for cooling. It is sunproof
and waterproof.
Door and Door Lock:
The cabinet door uses embedded structure. The door opening angle is
larger than 110° and the door limit device can limit the opening
angle. The lock is theftproof three point lock, supports padlock.
7. Packing and Shipping
