Line Interactive UPS Input Voltage 140-275Vac 40Hz-75Hz

    Buy cheap Line Interactive UPS Input Voltage 140-275Vac 40Hz-75Hz from wholesalers

    Buy cheap Line Interactive UPS Input Voltage 140-275Vac 40Hz-75Hz from wholesalers
    • Buy cheap Line Interactive UPS Input Voltage 140-275Vac 40Hz-75Hz from wholesalers

    Line Interactive UPS Input Voltage 140-275Vac 40Hz-75Hz

    Ask Lasest Price
    Brand Name : ESTEL
    Model Number : MS1000-3000VA
    Certification : ISO9001, CE, 3C, FCC, TLC
    Price : 358-2143 usd
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 20,000 sets per month
    • Product Details
    • Company Profile

    Line Interactive UPS Input Voltage 140-275Vac 40Hz-75Hz

    Line Interactive UPS MS1000-3000VA


    True double-conversion
    Microprocessor control optimizes reliability
    Output Sine Wave
    Output power factor0.8
    Wide input voltage(140-275Vac)
    Converter mode available
    Generator compatible
    LCD display
    Short circuit,Overload,Overcharge and overdischarge protection


    Specification


    MODELMS1000MS2000MS3000
    CAPACITY1000VA/800W2000VA/1600W3000VA/2400W
    INPUTVoltage220Vac/230Vac
    Voltage Range140-275Vac
    Frequency Range40 Hz~75 Hz(auto sensing)
    OUTPUTVoltage Regulation(Batt.Mode)220Vac/230Vac±10%
    Frequency Range(Batt.Mode)50Hz±1Hz or 60Hz±1Hz(auto sensing)
    Transfer TimeTypical 2-8ms,13ms max
    Waveform(AC.Mode)Sine Wave
    Waveform(Batt.Mode)Sine Wave


    BATTERY
    Battery Voltage24V24V48V
    Battery number7AH*29AH*29AH*4
    Maximum Charge Current1.3A1.3A1.3A
    PROTECTIONFull Protectionshort circuit,Overload,Overcharge and overdischarge protection
    ALARMBattery modeSounding every 30 seconds
    Low BatterySounding 0.5 second
    OverloadSounding every 0.5 seconds
    FaultContinuously sounding
    PHYSICALApprox.Dimension
    DXWXH(mm)
    368x144.2×211455x190x330
    Approx.Net Weight(kgs)12.114
    OPERATING
    ENVIRONMENT
    Humidity0-90%RH @0-40℃(non-condensing)
    Noise LevelLess than 40dB(1m spacing)Less than 45dB
    (1m spacing)
    MANAGEMENTCommunication portRS232
    *Product specifications are subject to change without notice.
